Stainless Steel Threaded Rods | DIN975 All-Thread
SS304 / SS316 • Metric and Imperial Requests • Custom Lengths • OEM Supply
Product Overview
Youjia Metals supplies stainless steel threaded rods and all-thread studs for industrial fastening, construction, equipment installation, and solar mounting projects. A continuous external thread allows nuts to be positioned along the rod for connection, suspension, or adjustment.
Our published threaded rod range includes SS304 and SS316 materials, metric and imperial requests, and custom cut lengths. Specify the thread, length, material, strength class, end form, and inspection requirements for quotation. Availability and the final product specification are confirmed before an order is accepted.
Technical Specifications
| Parameter | Published Range / Ordering Requirement |
|---|---|
| Product | Stainless steel full-thread rod / all-thread stud |
| Metric Diameter | M2–M64; individual diameter and pitch subject to confirmation |
| Imperial Diameter | 1/8 inch–2-1/2 inch requests; specify the thread series and pitch |
| Length Range | 100–6000 mm, including custom cut-to-length requests |
| Listed Lengths | 1 m / 2 m / 3 m; current availability confirmed in the quote |
| Material | SS304 / SS316; SS316L and B8 / B8M specifications reviewed on request |
| Strength Class | A2-70 / A4-80 requests reviewed separately; do not infer strength class from material grade alone |
| Standard / Drawing | DIN975 legacy reference; specify DIN 976-1 or the required current standard and end form. ASME B18.31.3 requests reviewed separately |
| Finish Options | Bright polish / passivation / PTFE coating requests, subject to technical review |
| Custom Service | Metric or imperial thread, length, end preparation, and drawing-based requirements |
These ranges are retained from our published threaded rod listing. They are not a statement that every combination is stocked or suitable for every application.
DIN975 and DIN 976-1 Ordering
DIN975 remains a common legacy search and purchasing reference for threaded rods, but the standard has been withdrawn. Specify the required current standard, thread end form, dimensions, and tolerances in the purchase specification. Different standard references are not automatically interchangeable.
Threaded rod catalogs commonly list 1 m and 2 m lengths; your required length and any cut-end treatment must be stated in the inquiry. Standard length, stainless material designation, and strength class are separate requirements.
Materials and Manufacturing
SS304 can be considered for suitable general industrial environments, while SS316 may be considered where chloride exposure or other service conditions require a different material. Neither grade is corrosion-proof. Review the environment, operating temperature, maintenance, and required mechanical properties before selection.
Thread rolling and custom end preparation are reviewed against the diameter, material, and drawing. Double-end or partial-thread designs are custom alternatives rather than the same configuration as a full-thread rod. Thread pitch, dimensional inspection, and finish requirements are agreed for the order.
Applications and Installation
Typical projects include HVAC and ceiling suspension, pipe supports, machinery and OEM assembly, construction connections, marine installations, solar mounting, and chemical or food-processing equipment. Suitability depends on the joint design, service exposure, nut compatibility, required load, and installation method.
Stainless threads can gall. Discuss suitable lubrication, mating material, tightening method, and coating compatibility. No percentage increase in load capacity or automatic prevention of galling is claimed. Do not use an unspecified rod as a rated lifting component.
OEM Supply, Inspection, and Packaging
Provide a drawing or complete specification for custom diameter, pitch, length, end form, material, finish, and quantity. Material identification, dimensional checks, thread gauging, mechanical tests, traceability, and test documents must be specified and agreed before production.
Carton, pallet, wooden-case, or OEM-labeled packaging requests are reviewed according to rod length, quantity, and shipping method. Lead time, stock status, sample requirements, and document availability are confirmed in the quotation rather than promised for every order.
Threaded Rod FAQ
Provide the exact thread diameter and pitch, length, end form, material, and quantity. The published range is M2–M64 and 100–6000 mm, with imperial requests also reviewed. Each combination requires confirmation.
No. Material designation and mechanical property class are separate. State the required class and verification documents in your order specification.
Yes, inquiries for solar mounting, construction, and industrial fastening can be reviewed. Provide the loads, installation arrangement, exposure conditions, and drawing so suitability can be assessed.
Send your drawing, thread, material, finish, quantity, inspection requirements, and delivery destination through our contact page.
Related Products
Browse threaded rods, matching nuts, and fasteners. Confirm thread and strength compatibility before combining parts.
Request a Threaded Rod Quote
Send diameter, pitch, thread series, length, end form, material, property class, finish, quantity, application, inspection documents, packaging, and destination.
